If I have a torque value of, let's say, 100 Nm, am I right in saying that it takes 100 Joules of energy to

__generate__that torque since 1 Nm = 1 Joule.

You are using an out of date browser. It may not display this or other websites correctly.

You should upgrade or use an alternative browser.

You should upgrade or use an alternative browser.

- Thread starter electerr
- Start date

- #1

- 28

- 0

If I have a torque value of, let's say, 100 Nm, am I right in saying that it takes 100 Joules of energy to

- #2

Doc Al

Mentor

- 45,246

- 1,594

No, that's not right. Even though torque is measured in Nm, and a Nm is dimensionally equivalent to a Joule, that does not mean that torque and energy are the same thing or that it is correct to measure torque in Joules. (Joules are reserved for energy--never used for torque.)If I have a torque value of, let's say, 100 Nm, am I right in saying that it takes 100 Joules of energy togeneratethat torque since 1 Nm = 1 Joule.

And generating a torque doesn't necessarily require any energy at all, just as generating a force doesn't.

- #3

- 32,140

- 9,062

- #4

- 28

- 0

Got it. Thanks

- #5

jtbell

Mentor

- 15,825

- 4,210

- #6

- 28

- 0

- #7

Doc Al

Mentor

- 45,246

- 1,594

Sure.

Note that work = torque*angle is the rotational equivalent to work = force*distance.

- #8

- 35,977

- 4,683

Pay attention to the post regarding "scalar" versus "vector". For example, what happened if you've moved for the whole 2pi radians when the force is conservative? How much work have you done?

Zz.

- #9

Doc Al

Mentor

- 45,246

- 1,594

- #10

- 28

- 0

- #11

Doc Al

Mentor

- 45,246

- 1,594

No. If you apply a torque of 100 Nm continuously through an angle of 2π radians, then the work you do is 100*2π = 200π Joules.I wasn't asking about conservative forcebut I believe the answer to the question posed by ZapperZ is 0 Joules since the distance between the starting point and the ending point is 0, then 0 * 100Nm = 0 Joules, or...?

Edit: Since

Last edited:

- #12

- 32,140

- 9,062

The work done by a conservative force around a closed path is 0 so I think that a conservative force cannot apply a continuous torque through an angle of 2pi radians. If we look at the torque on a wheel due to the conservative force of gravity we see that the net torque is 0 (otherwise it would spontaneously spin faster and faster).

Last edited:

- #13

- 17

- 0

Hi There

I don't know for sure, but, if we know the circumference of the circle and apply a 10 N.m torque * 2randians (and 2rads = 2 meters of circumference travel)

Then 10n.m * 2m = 20N.m of work? And I presume that also = 20 joules?

Willy

I don't know for sure, but, if we know the circumference of the circle and apply a 10 N.m torque * 2randians (and 2rads = 2 meters of circumference travel)

Then 10n.m * 2m = 20N.m of work? And I presume that also = 20 joules?

Willy

Last edited:

- #14

Doc Al

Mentor

- 45,246

- 1,594

No. The work done is torque*angle, not torque*distance. (Check the units!)I don't know for sure, but, if we know the circumference of the circle and apply a 10 N.m torque * 2randians (and 2rads = 2 meters of circumference travel)

Then 10n.m * 2m = 20N.m of work?

(Realize that this thread is several years old.)
